Empire Rushmore TruFlame Direct-Vent Fireplaces 40"

DVCT40CBP95N

Gas Type: NG (Natural Gas)

Rushmore TruFlame Direct-Vent Fireplaces 40"

The Renegade's TruFlame Technology ensures maximum flames and ember glow with minimum emissions.

An attractive clean-face design integrates the barrier screen flush with the fireplace front – allowing  you to install tile, brick, or other non-combustible materials right up to the fireplace opening for a clean, organic installation.  Or choose one of the optional decorative fronts, doors, or frames to tailor your new fireplace with the look that suits your décor.

A variety of liners are available to further customize the Renegade– including Traditional Stone, Cottage Brick, or reflective Black Porcelain. Add the available hand-forged andirons to complete the look.

The Renegade fireplace is available in two sizes– 40-inch or 36-inch.


PRODUCT DIMENSIONS

Glass Viewing Area:

      • Width: 36"
      • Height: 30 3/8"

Framing:

      • Width: 49 1/2"
      • Depth: 24"
      • Height: 53 1/2"

Actual Dimensions:

      • Width: 49"
      • Depth: 24"
      • Height: 42 3/4"


TECHNICAL INFORMATION

  • Max/Min Heat Output:

      • 45,000/35,000 BTU (LP)
      • 47,500/30,000 BTU (Nat)

  • Weight: 317 lbs
  • Clearances:

      • Back: 0"
      • Side Wall: 2"
      • Floor: 0"
      • Top of Unit: 24"
      • Top of Framing Edge: 0"

  • Type of Gas: LP or Natural
  • Iron Pipe Size: 1/2-inch
  • Ignition Systems: Multi-Function
  • Vent Size: 5 x 8 inch
  • Top Vent Only (12-inch rise before horizontal)


This Unit Includes:

✓ Fine Mesh Barrier
✓ Non-Combustible Board
✓
Multi-Function remote to control the Front and rear burner 6-step variable flame height

      • Independent Rear burner on/off (70% turn down)
      • Accent lighting on/off with 6-step dimming
      • Optional Double Blower on/off with 6-speed settings


✓ TruFlame Technology Catalyst allows large flame, extensive ember bed and clean burn


This Unit Requires:

✓ Liner
✓ Log Set


FIELD-INSTALLED ACCESSORIES

  • Liners

      ‣ Black Porcelain Walls, Matte Floor and ceiling
      ‣ Old World Stone Walls, Floor, Ceiling
      ‣ Rustic Branded BRick Walls, Floor, Ceiling

  • Twin Blower
  • Andirons: Matte Black


WARRANTY

10-year Limited Warranty on Combustion Chamber, Limited Lifetime on Glass.  All other parts carry a three-year limited warranty.  All remote controls carry a one-year limited warranty.


Empire Rushmore TruFlame Direct-Vent
Fireplaces 40" Specification Guide

Empire Rushmore TruFlame Direct-Vent Fireplaces 40

Empire Rushmore TruFlame Direct-Vent
Fireplaces 40" Installation Manual

Empire Rushmore TruFlame Direct-Vent Fireplaces 40
