Vienna Linear Style Gas Fireplace by Sierra Flame

VIENNA-40-LP


Quick Specs

🔥 Fuel Type:  Gas

📦 Weight: 305lbs

Size: 40"
Gas Type: Liquid Propane

🚚 Typically leaves warehouse in 1-2 Weeks

The Vienna Linear Style Gas Fireplace

The Vienna linear gas fireplace uses radiant thermal convention technology. This allows heat from the fire to naturally enter the room using airflow pulled in from the room in combination with variable fans that then propel the convention-heated air through the double glass channel. Screen-free and cool touch with aesthetic and safety in mind.

The Vienna Heat Sheild Now Lets You Enjoy:
Clear View: Double Wall Glass Technology • Clear View has done away with the need for distractive safety screens. The double shield glass, protects hands from burning, while you can enjoy uncompromised views of your stunning fireplace.

Warm Glass System: Safety Touch Glass • The Warm Glass System, skillfully brings the temperature of the glass down below the stringent standard of 172 degree, while still allowing radiant heat to efficiently heat your room.

Easy Clean: No technician Required • With the easy maintenance glass removal system, you won’t need a service technician to come and clean our fireplace viewing glass area.



Product Dimensions

40" Vienna:
  • Weight: 286 lbs
  • Height: 32 5/9"
  • Width: 49 1/9"
  • Depth: 18 1/6"
50" Vienna:
  • Weight: 305 lbs
  • Height: 32 5/9"
  • Width: 60"
  • Depth: 18 1/6"
60" Vienna:
  • Weight: 270 lbs
  • Height: 32 5/7"
  • Width: 42 2/7"
  • Depth: 18 1/2"



Features:

»   Linear Style
»   Available in: 40", 50", and 60"
»   Glass Viewing Area:

  • Vienna 40":  15.30" H x 36.71" W
  • Vienna 50":  15.30" H x 46.71" W
  • Vienna 60":  15.30" H x 56.71" W

»   BTU:

  • Vienna 40": Hi 28,000 / Low 17,000
  • Vienna 50": Hi 28,000 / Low 17,000
  • Vienna 60": Hi 36,000 / Low 21,500

»   No Gaps, No Louvers, No Screens
»   Able to Finish with Combustible around Fireplace
»   Clear View: Double Wall Eliminates Need for Safety Screen
»   Easy Clean, no Technician Required to clean the Glass Viewing Area
»   Natural Gas or Liquid Propane
»   Double Glass & Screen Free
»   All Wood Framing
»   No Concrete Board Required

No Gap • With a lot of fireplaces, they need to create an escape for the heat to vent out. To do this, they leave a gap at the top of the fireplace wall to create a crown to hide the opening. A gap is not necessary.

No Intake or Exhaust Louvres • Your wall will not have any intake or exhaust louvers to break up the look

No Heat Dump • There are no vents required behind the wall of the fireplace to dump the built up heat.

Combustibles Okay • Everything is contained within the firebox. Able to finish with combustibles around the fireplace. No special concrete board or metal studs



Optional Accessories:

‣   Termination Kit - 5" & 8" Venting (Gen Term Kit)
‣   Duravent 5 PC Through The Roof Kit (TTRK 5&8)
‣   Duravent 5 PC Through The Roof Kit - Steep (TRRK 5&8-S)



Gas Fireplace Warranty

The Vienna Specification Sheet & Installation Manual

40" | Vienna 40in Linear Gas Fireplace Spec SheetVienna 40in Lienar Gas Fireplace Installation Manual

50" | Vienna 50in Linear Gas Fireplace Spec SheetVienna 50in Lienar Gas Fireplace Installation Manual

60" | Vienna 60in Linear Gas Fireplace Spec SheetVienna 60in Lienar Gas Fireplace Installation Manual
