Bennett 45" Direct Vent Linear Gas Fireplace by Sierra Flame

The 45" Bennett Direct Vent Linear Gas Fireplace

The stylish Bennett 45L gas fireplace offers you a choice of black metal surround with safety barrier or decorative stainless steel surround with safety barrier. Your choice. The Bennett 45 is gorgeous either way! It will keep you warm.

Bennet Fireplace Features

• BTUs

• Hi 30,000 NG / 27,000 LP
• Low 22,000 NG / 19,500 LP

• Venting **

• 4" Flex Vent on Exhaust Side
• 7" Flex Vent on the Air Intake Side
  **Venting - Any certified 2-ply flex piping can be used. Certified on Duravent, Selkirk, Metal Fab, ICC

• Ceiling/Mantle Height

• Internal Ceiling: 58"
• Mantle Height Minimum: Minimum 42"

• New Builds & Renovations
• Commercial Spaces
• Restaurants
• Condominiums


Fireplace Dimensions

Included Accessories

Surround Options:

Trim & Barrier Required to complete the fireplace installation.

• Basic Black Surround with Safety Barrier

• 26.10" H x 49.46" W
• Weight: 30 lbs

• Clean Face Surround

• 30" H x 53. 17"W
• Weight: 30 lbs

Optional Accessories

Fire Glass & Designer Media Kits

• RUSTIC - 14 Piece Design Media Kit. This includes:


• Decorative Media Fire Glass

• Our decorative fire glass media is a beautiful addition to your fireplace. Turn your fireplace into a expressive work of art by simply adding our
  decorative fire glass media. Our fire glass adds a distinctly modern feel to your gas fireplace - mix colors and textures for a unique appearance.

  Our decorative fire glass is tempered and will not melt or degrade, some discoloration is normal on glass that is placed directly on the flame.
  Always wear protective gloves when handling fire glass media.

  One 5lb container of media will cover 1 square foot.

Venting

• Termination Kit


• Termination kit for 4" & 7" vent Includes: 1 wall thimble, Horizontal term vent, No flex included.
• * Must supply own flex or purchase 10' 4" x 7" flex length only
• Size: 4"
• Color: Black
• Termination kit for 4 x 7" venting
• Venting Requirements: This unit requires a venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for the venting pipe that must be used with this unit.

• Horizontal Flex Term Kit


• SKU: SF94217405
• If 5' of flex is required, use this kit:
• "4”X 7” Horizontal Flex Termination Kit w/ 5’ of Flex, Horizontal Termination, Wall Thimble.
• Includes Coaxial flex lengths, horizontal termination, wall thimble, screw package, sealant

• 4" x 7" Coaxial Flex, 10' Length


• SKU: SF94207410
• To extend SF94217405 an additional 10' purchase this:
• 4” X 7” Coaxial Flex
• 10’ Length Extends SF94217405 – 5’ Flex Kit Couplers Sold Separate – SF942074C

• 4" x 7" Couplings

• SKU: SF942074C
• 4” X 7” Flex Extension Coupler Kit (1-4” & 1-7”)
• Includes 2 couplers, 1 for the inner flex and 1 for the outer flex
• Size: 4"
• Color: Stainless Steel
• One 4" flexible vent pipe coupler
• One 7" flexible vent pipe coupler
• 4" x 7" flexible vent pipe extension coupler kit

• Dura-Hard Vent Pipe Adapter

• SKU: DURA-HARD
• For Hard pipe only installations
• Adapter to use hard pipe off of fireplace
• Transitional adaptor
• Constructed from galvanized steel
• Connects flexible vent pipe to rigid vent pipe
• Size: 4"

• Dura-Flex Vent Pipe Adapter

• SKU: DURA-FLEX
• To convert from flex to hard pipe
• Galvanized adapter to go from flex to hard pipe
• Transitional adaptor
• Safely transitions flexible vent pipe to rigid vent sections
• Size: 3"

Gas Fireplace Warranty
Sierra Flame Gas Brochure
Bennett Log Placement Guide

Bennett 45" Specification Guide

Bennett 45" Installation Manual
